The AquaSport has a generous streamlined swim tank area and flat ergonomically designed anti-slip floor that allows for a variety of fitness exercises. Additionally, the swim spa is a safe and easy environment in which to teach kids how to swim.
. 2 x Accu Flow Swim Jets, 1 x Buoyancy Jet
. 1 x HydroClean Filtration Pump
. 1 x 4 HP Evergreen Single Speed Pump
. 1 x 5 HP Aqua Boost Swim Pump
. 1 x 4 Kw Heater - Optional upgrade to 2nd 4kw Heater
. 4 Persons Hydrotherapy Seating
. 29 Stainless Steel Hydro Flow Hydrotherapy Jets
Shell Dimension
172.75" x 91.75"
442 cm x 236.2 cm
Height
52.75"
134 cm
Usable Swim Area
117" /297 cm
Volume
1,908 US gallons
7,220 L
Weight Full
18,413 lbs
8,354 Kg
Weight Empty
2,500 lbs
1,134 Kg
Estimated Monthly Electrical Cost *
$47.12 - $104.37
. 2 x Accu Flow Swim Jets, 1 x Buoyancy Jet
. 1 x HydroClean Filtration Pump
. 1 x 4 HP Evergreen Single Speed Pump
. 1 x 5 HP Aqua Boost Swim Pump
. 1 x 4 Kw Heater - Optional upgrade to 2nd 4kw Heater
. 5 Persons Hydrotherapy Seating
. 31 Stainless Steel Hydro Flow Hydrotherapy Jets
Shell Dimension
211.25" x 91.75"
537 cm x 233 cm
Height
52.75"
134 cm
Usable Swim Area
153" /389 cm
Volume
2,409 US gallons
9,120 L
Weight Full
22,800 lbs
10,345 Kg
Weight Empty
2,700 lbs
1,225 Kg
Estimated Monthly Electrical Cost *
$54.14 - $120.04
SWIM SPA
1 x 4HP Evergreen Two Speed Pump
1 x 5 HP Aqua Boost Swim Pump
2 x Accu Flow Swim Jets
1 x Buoyancy Jet
1 x 4Kw Heater (optional upgrade to 2nd 4kw heater)
1 x HydroClean Filtration Pump
HOT TUB
4-5 Persons
1 - 4HP Evergreen Two Speed Pump
1 - HydroClean Filtration Pump
35 Stainless Steel Hydro Flow Hydrotherapy Jets
Shell Dimension
224.75" x 91.75"
571 cm x 233 cm
Height
52.75"
134 cm
Usable Swim Area
124" /315 cm
Volume
2,203 US gallons
8,338 L
Weight Full
21,317 lbs
9,672 Kg
Weight Empty
2,940 lbs
1,334 Kg
Estimated Monthly Electrical Cost *
$57.60 - $126.72
Customizable Current: Jet Flex Swim System
. The system produces 5 kph current
. The current speed is adjustable
. You can vary the flow of water and adjust its intensity
Aquachannel Shell Design: Complete Loop Design
. Shell hips designed to create an eddy in the seating area
. No reflective wave
. Keeps swimmer in swim lane
Pumps: Produce a strong current
. 1 x 5HP AquaBoost Pumps produces up to 360 gallons per minute
. 1 x 4HP Buoyancy Pump located under Swim Jets
Hydraulics: Energy Efficient
. Suction located on the step in seating area eliminates turbulence
. 2.5 inch intake and return pipes move more volume of water
. All pumps are Evergreen Efficient using 30% less amperage than a traditional pump
Slipstream Swim Jet Technology: Great for Exercise
. Two AccuFlo Jets produce the swim current
. Oval Design flattens the water flow for a smoother swim
